Schräder valve core
Maximum working pressure with static load 60 bar, dynamic 20 bar.
Opening pressure 5 bar with about 25% tolerance.
Tightening torque 0.25-0.3Nm.
Temperature range -40 to 100°C (briefly 120°C).
Teflon and Neoprene gasket.
Suitable for R12, R22, R134a, R1234yF, R290, R404A,
R407C, R410A, R417A, R502, R507, CO2 and Ethanol.
Description on packaging:
A-31999
Examples and applications or
Names and unit codes:
31999
N800-2503
HP-55-2998
HP-55-2998S
