This part is interchangeable but not original Carrier.
Mentioned names, descriptions or article numbers of manufacturers or material brands are only mentioned as reference and description.
In such a case, this does not in any way imply that these parts are original parts of the manufacturers concerned.
You can of course also buy these from the mentioned registered trademark dealer of this part or order the original part from us.
Overhaul Kit
For Carrier Transicold Unit Type:
Maximum
Maxima Plus / MaximaPlus
Maxima 2 / Maxima2
Maxima II / MaximaII
Maxima 1000 / Maxima1000
Maxima 1200 / Maxima1200
Maxima 1200Mt / Maxima1200Mt
Maxima 1300 / Maxima1300
Maxima 1300Mt / Maxima1300Mt
diesel CT4-91TV/CT4.91TV
List of parts of this kit for Carrier Transicold:
1x Gasket set HC-251501501
4x Piston and Springs HC-7103034
1x Oil pump HC-945530
4x Inlet valve HC-945572
4x Exhaust valve HC-945573
4x Inlet Valve Guide HC-945521
4x Exhaust Valve Guide HC-945522
1x Bearing Axial HC-945748
1x Bearing Crankshaft 0.20 HC-945622
4x Bearing Connecting Rod 0.20 HC-945606
1x Bearing Crankshaft 0.20 HC-945616
1x Bearing for Camshaft Fuel Pump HC-945669
1x Bearing rear Camshaft Fuel Pump HC-945125
3x Bearing Crankshaft 0.2 HC-945746
4x Bearing Bush Connecting Rod HC-945759
4x Glow plug HC-7100833
1x Pipe HC-945733
1x Water pump HC-297026201SK
6x Plug HC-944003
1x Plug HC-941402
1x Plug HC-942002
1x Plug HC-945506
1x Plug HC-945503
3x Plug HC-941401
3x Plug HC-7103017
1x Sleeve Crankshaft HC-945612
1x Crankshaft Sleeve HC-945613
1x Oil Pressure Switch HC-120059200
