Appliance socket Flange Bals Type 28010
Brand Bals
flange 75x75
mounting centers 60x60
Protection class (IP) IP44
Number of poles 3
Material Plastic
Insertion direction Straight
With phase change No
RAL number 5015
Hour position 6 h
Military version No
Connection technology Screwless clamp
IEC current rating 32 A
Characteristic color Blue
Voltage according to EN 60309-2 230 V (50+60 Hz) blue
Height 75mm
Width 75mm
Depth 96mm
Description on Article:
Bals
32- 6h
200-250
2P+PE
IP44
Typ28010
Made in Germany
Description on packaging:
Applications and Examples or
Names and product codes:
It is not allowed to copy this.
20165126
401086486
FBQF86
00282967
2850055042
Old item number 2850055042
Attachment plug
