Description:
Spal Fan/ Spal Blower
Spal 005-A45-02 3VCB RPA
Proof tension 13V
Electric consumption (A) 14,4 A
Air flow (m3/h) 610 m³/h
Voltage 12V
Speed 3
New Spal Code 005-A45-02 3VCBRPA
Spal productor Code 3000.1803
Basic length 304 mm
Weight (KG. abt.) 1,5 kg
Spal® Old Artikelcode :
Description on Article:
Logo Spal
e1 03 2750
Type 005-A45-02-12V
Made in Italy
1642 gram
On Resistor:.5+.5-216/22
Technical specifications:
AC-3000.1802.pdf
NOTE, these are the specification of the 1802. The 1803 is a BL304 version, with a width of 304mm instead of 317mm.
Applications and Examples or
Names and product codes:
It is not allowed to copy this.
AC-3000.1803/AC3000.1803
AC 3000.1803
AC-30001803/AC30001803
AC 30001803
AC-005-A45-02/AC005-A45-02
AC 005-A45-02
AC-20220219/AC20220219
AC 20220219
