This Compressor version
TM16HS-TM16HD)
Always without magnetic coupling / Clutch
Evt. is the right oil / coupling loose when ordering
Look below: Order accessories
Zexel / Tama / Valeo
Description Air Compressor:
TM16 HS
AC Compressor: TM16 HS TM16HS (TM16-HS)
Connection:
Connection:
Compressor info:
Capacity: 163cc
Refrigerant: R134a
Oil type: Delivered with oil
Quantity of oil: 180 ml
Oil type of us see Photo
Connection Type:
Coupling suction:
Clutch Press:
Mounting: 4 mounting ears
With hole size Ø10,3
Heart Size Hole / Hole 104mm
Cylinders: 6
Rotation: CW / CCW
Link / Cluts info:
Tours range: 700-6000 RPM
Compressor type:
Seltec / Zexel TM-16HS / TM-16HS / TM-16HS
Connection:
Housing Type: Z0006401
B (mm) 39.5 mm / B (mm) 46.5 mm
C (mm) 83.3 mm
Description on Aircompomp:
Seltec
HFC134a Model TM-16HS
Body No.Z0006401A
LUB. CM³
LEAK.TEST Hi / Lo: 2.9 / 1.5 MPaG
Made in Japan
Net 7400 grams
According to the rules art.SAE-J639
Examples and applications or
Designations and item codes:
