Description TM 13 HS OR Horizontal 24V Ø125mm (5"1/4) 2A
Displacement 131 cc
N° Cylindres 6
Refrigerant R134a
Oil Type ZXL 100PG (or Equiv.)
Oil Quantity 150 cc
RPM Max. 6000 r.p.m.
Installation position ± 45°
Rotation Clockwise
Suction fitting :(G10) 7/8" 14UNF
Discharge fitting :(G8) 3/4" 16UNF
Pulley Diameter Ø125mm (5"1/4)
Voltage 24V
Number of grooves 2 "A"
Section Groove (S) 12,7 mm
Type SL= Spring Leav
Compressor TypeZexel TM13
Fittings O.Ring
B (mm) 53,9 mm
C (mm) 83 mm
Seltec
Description on Article:
HFC134a Model TM-13HS
Body No.Z0006329A/Z0006318C
C208105T
LUB.ZXL100PG 150 CM³
LEAK.TEST Hi/Lo:2.9/1.5 MPaG
Made in Japan
Netto 7,2 kg
Applications and Examples or
Names and product codes:
It is not allowed to copy this.
Pompairco/ACpomp/Aircocompressor
www.autoclima-parts.nl
www.Hattink-ThermoParts.com
AC-40430016/AC40430016
AC 40430016
ac-Z0006329A/AC Z0006329A
Direct Drive Compressor TM13 Type Tama
Compressor Konvecta TM13
Compressor Seltec TM13HS
Seltec Compressor TM13 HS
Zexel Compressor TM13HS
Compressor Zexel TM13 HS
Compressor TM13 R404a
Compressor R134a TM13HS
R134a Compressor Seltec/Zexel
Compressor Valeo Nr.40430016
Aircopomp Valeo 404300016
Aircopomp Seltec TM13HS
Seltec Aircopomp TM13 HS
Zexel Aircopomp TM13HS
Aircopomp Zexel TM13 HS
Aircopomp TM13 R134a
Aircopomp R134a TM13HS
R134a Aircopomp Seltec/Zexel
Aircopomp Valeo Nr.40430016
