This Compressor version
QP15
Always comes without
a magnetic clutch / clutch supplied
possibly is the correct oil/clutch available separately
Look under: Order accessories
Low Temperature Compressor
for refrigeration Direct drive
such as Carrier / Thermoking
Frigosoft / Zanotti / Govet / Kerstner
Konvecta / Davia / Cibin / Webasto.
Zexel/Tama/Valeo
Description Airco Compressor:
QP15
AC Compressor:QP15 QP15 (QP15)
Connection:
Connection:
Compressor info:
Capacity: 147cc
Refrigerant: R134a
Oil type: Supplied with oil
Amount of oil: 150 ml
Oil type from us see Photo
Connection Type:
Clutch Press:
Mounting: 4 mounting ears
with hole size Ø10.3
Heart size Hole/Hole 104mm
Cylinders: 6
Rotation: CW/CCW
RPM range: 700-6000 RPM
Compressor type:
Seltec/Zexel QP15
Connection:
Enclosure type: Z0006351A
W (mm) 39.5mm / W (mm) 46.5mm
C (mm) 83.3mm
Description on Air conditioning pump:
Seltec
Model QP15
Body No.Z0006351A
LUB. CM³
LEAK.TEST Hi/Lo:2.9/1.5 MPaG
Made in Japan
Net grams
According to the rules art.SAE-J639
