No oil in the compressor supplied
Description QP15 XD OR Vertical 24V Poly-V 8V
Displacement 146,7 cc
Refrigerant R404a
Oil Quantity 0 cc
Suction fitting 7/8" 14UNF
Discharge fitting 3/4" 16UNF
Pulley Diameter Ø 119 mm
Voltage 24V
Number of grooves 8 Poly-V
Section Groove 3,56 mm
Compressor Type QP15XD
Koppeling type: 3 Eye
Fittings OR V.
B (mm) 60,8 mm
C (mm) 83 mm
Description on Article:
Made in China
Net 7400 gram
Interchangeable with AC-40430169
Applications and Examples or
Names and product codes:
