NB!!! No oil included in compressor
and O-rings are also not included.
See photos.
QP15XD-1635
Que
Compressors 12V:
Description Air conditioning Compressor:
AC Compressor:QP15XD
Connection: O-ring
Coupling Type: 3-Eye
Voltage: 12V DC
Ø132mm A2
Connection: Horizontal
Compressor info:
Capacity: 147cc
Refrigerant: (XS/HD) R404a/R452a
Oil type: Supplied without oil
Quantity of oil: 150 ml
Oil type from us: see photo
Connection Type: O-Ring
Coupling Suction:(G10) 7/8" 14UNF
Coupling Press:(G8) 3/4" 16UNF
Mounting: 4 mounting ears
with hole size Ø10.3
Heart size Hole/Hole 104mm
Cylinders: 6
Rotation: CW/CCW
Clutch/Cluts info:
Pulley at groove: Ø132mm
Voltage: 12V DC
Connection: 1x wire + side / Ground is Body
Number of grooves: 2 Type A2
Speed range: 700-6000 RPM
Compressor type:
Que QP15 XD / QP-15XD / XD
Connection: O-ring
Description on Air conditioning pump:
Logo QUE
Model QP15XD-1635
Made in China
Net 7.4 kg
QP15 XD-1635
QP15XD1635
QP15 XS-1635
QP15XS-1635
